Draw with precision
Primitives, pen/bezier paths, node editing, dimensions, and boolean weld/trim/intersect — with units in px, mm, cm, or inches.
2D editor · mechanical parts · laser-ready
Draw parts. Tag operations. Cut with confidence.
Vector Art is a browser-based 2D vector workspace for mechanical parts, sheet assemblies, and fabrication drawings — from first sketch to SVG/DXF export with cut, engrave, and score operations.
- Precise 2D geometry
- Laser ops & kerf
- SVG & DXF export
Built for fabrication workflows
Mechanical parts
Finger joints & gears
Weld · trim · intersect
Nest layout
Assembly Line 3D
From 2D geometry to machine-ready files.
Design mechanical parts, sheet assemblies, signage, and classroom kits in one workspace — then validate assemblies in 3D before you cut.
Generators & imports
Finger-joint panels and boxes, parametric gears, bitmap trace, and import from SVG, DXF, CDR, or AI — then edit as real vector geometry.
Production handoff
Tag cut/engrave/score operations, apply kerf compensation, run preflight checks, nest on sheet stock, and export clean SVG or DXF.
2D editor plus optional 3D validation.
The canvas is your source of truth. Assembly Line and 3D previews help you check fit before fabrication — without replacing a full MCAD kernel.
Browser workspace
Open the editor at /app from any modern browser — no install required.
Cloud projects
Save designs to your account, reopen from the dashboard, and share preview links when enabled.
Assembly Line
Mate 3D parts from DXF profiles, build assemblies, and check interference before cutting sheet stock.
Enterprise teams
Invite members, organize team projects, and standardize templates across a shared workspace.
Start a design. Export when it measures true.
Sign in, open the editor, and build fabrication-ready vector work in the browser.
